Hnab Cell Case Forming Tshuab
Order (Moq): 1set
Ua raws li: CE Certified
Pob: Plywood Case
Khoom Keeb Kwm: Tuam Tshoj
Warranty: Ib xyoos lav nrog kev txhawb nqa lub neej
Kev Them Nyiaj: T / T, Western Union, Paypal, Ali Trade Assurance
Polymer Battery Pouch Cell Case/Cup Forming Machine for Aluminium-Laminated Films
Product Description
Lub hnab ntawm tes cov ntaub ntawv ua tshuab yog tsim nyog rau cov kub flattening thiab shaping ntawm cov tub ntxhais hluav taws xob tom qab winding, uas yog yooj yim rau nkag mus rau hauv lub plhaub. Lub qhov txhab ntawm tes yog muab tso rau hauv lub template los tsim lub cell los ntawm lub siab thiab cua sov kom ua tiav tib lub thickness ntawm lub cell, txo elasticity ntawm lub cell, txo qhov luv luv Circuit Court tus nqi ntawm cov tub ntxhais thiab xyuas kom meej qhov sib xws ntawm lub thickness ntawm cov tiav. cell. Tsis siv neeg thermoforming tshuab
Nta
* Qhov kub ntawm qhov chaw ua haujlwm tuaj yeem hloov kho los ntawm lub pob ntawm lub ntsuas cua sov. Tus nqi tam sim no thiab tus nqi ntawm cov txheej txheem kub tuaj yeem tso tawm ntawm LCD zaub, uas yog intuitive thiab meej, nrog rau kev tswj kub kub thiab kev ua haujlwm yooj yim;
* Lub siab ntawm lub rooj ua haujlwm sab saud thiab qis tuaj yeem hloov kho los ntawm lub siab tswj lub valve kom ua tau raws li qhov yuav tsum tau ua ntawm cov txheej txheem sib txawv;
* Lub tshuab txais ib qho chaw nres tsheb qauv, sab sauv thiab sab hauv lub rooj ua haujlwm yog qhov sib luag, thiab cov qauv ruaj khov thiab txhim khu kev qha;
* Qhov chaw ua haujlwm yog ua los ntawm cov ntaub ntawv zoo, nrog rau cov khoom siv hluav taws xob zoo, txuag hluav taws xob thiab txhim kho kev ua haujlwm;
* Siv cov khoom siv tiv thaiv kab hlau rhuav, nyab xeeb siv;
* Lub tshuab no muaj qhov ntsuas kub txawv txav;
* Thaum tshav kub kub nias, kub thiab siab tuaj yeem hloov kho;
* Lub tshuab no txais kev tswj tsis siv neeg thiab semi-automatic, yooj yim rau kev khiav lag luam;
* Me me, tuaj yeem txuag chaw;
* Exquisite tsos, cov ntawv hlau txais peb-dimensional geometric tsim, uas yog yooj yim thiab zoo nkauj;
* Kev tswj hluav taws xob tuaj yeem siv rau kev ua haujlwm tsis siv neeg thaum lub sijhawm ua haujlwm, thiab phau ntawv muaj nuj nqi tuaj yeem siv tau thaum kev debugging.
Specification
| Fais fab mov: | AC220V / 50Hz; hwj chim: 1.5KW; | ||||||
| Cua qhov chaw: | 0.5Mpa-0.8Mpa | ||||||
| Thaum tshav kub kub pressing cheeb tsam: | 200x200mm; | ||||||
| Siab: | 1T siab adjustable; | ||||||
| Kub tswj qhov tseeb: | ± 2 degree; | ||||||
| Qhov kub thiab txias: | ib txwm kub ~ 200 degree adjustable; | ||||||
| Nws dav hlau parallelism ntawm ob lub phaj siab: | hauv 0.05 | ||||||
| Khoom siv loj: | 320mm X 325mm X 560mm | ||||||
| Qhov hnyav: | 90kg ua. | ||||||
Khoom Paub meej
