Electrode Tuag Cutter
Order (Moq): 1set
Ua raws li: CE Certified
Pob: Plywood Case
Khoom Keeb Kwm: Tuam Tshoj
Warranty: Ib xyoos lav nrog kev txhawb nqa lub neej
Kev Them Nyiaj: T / T, Western Union, Paypal, Ali Trade Assurance
Hnab Cell Battery Electrode Tuag Cutter Rau Kev Tshawb Fawb
Product Description
Lub hnab cell roj teeb electrode tuag cutter rau kev tshawb fawb hauv chav kuaj yog cov khoom siv rau kev tuag-txiav zoo thiab tsis zoo daim hlau ntawm lithium roj teeb laminates. Cov cuab yeej siv lub tog raj kheej pressurized rau xuas nrig ntaus ib qho los yog coiled ncej, thiab tuaj yeem muab ntau yam duab ntawm riam tuag raws li cov neeg siv khoom kom paub txog kev tsim thiab tuag-txiav ntawm cov roj teeb ncej ntawm ntau qhov sib txawv.
Nta
- Siv infrared positioning ntaus ntawv, muaj tseeb thiab yooj yim ncej piece positioning tuag-txiav.
- Nws yog qhov yooj yim thiab ceev hloov cov riam pwm.
- Lub neej ntev, siv ib txwm siv ntau dua lossis sib npaug li 30,000 zaug.
- Tsis muaj qhov tsis zoo xws li burrs, hmoov poob, thiab indentation.
- Nruab nrab ntawm phau ntawv thiab tag nrho tsis siv neeg, kev ua haujlwm siab 800-2000 daim / teev (Raws li qhov luaj li cas ntawm qhov txiav ncej, 1-8 daim tuaj yeem xuas nrig txhua zaus, tus qauv yog 2 daim)
- Siv plaub tus ncej ncej qauv, zawv zawg nce thiab nqis smoothly thiab siab precision.
- Cov khoom siv inlet muaj kev tiv thaiv lub teeb pom kev ruaj ntseg, uas ua rau kev ua haujlwm zoo heev.
- Exquisite tsos, cov ntawv hlau txais peb-dimensional geometric tsim, uas yog yooj yim thiab zoo nkauj.
- Yooj yim rau kev khiav lag luam, nyab xeeb thiab txhim khu kev qha, me me.
- Siv infrared positioning ntaus ntawv, muaj tseeb thiab yooj yim ncej piece positioning tuag txiav
- Vertical burr Tsawg dua lossis sib npaug li 15μm, kab rov tav burr Tsawg dua lossis sib npaug li 20μm
- Lub neej ntev, siv ib txwm siv ntau dua lossis sib npaug li 30,000 zaug
- Pneumatic-kua pressurized lub tog raj kheej tsav, xuas nrig ntaus quab yuam thiab xuas nrig ntaus ceev yog adjustable.
- Nrog kev ruaj ntseg tiv thaiv lub teeb kab hlau rhuav
Specification
|
Punching loj: |
280x180mm (tuaj yeem ua raws li cov neeg siv khoom xav tau) |
|
Punching precision: |
± 0.1 hli |
|
Booster cylinder: |
3T |
|
Tuag txiav stroke: |
150 hli |
|
Muaj peev xwm: |
800-2000EA/H (daim ntawv tuag txiav efficiency qis dua me ntsis) |
|
Fais fab mov: |
220V / 50Hz |
|
Lub zog: |
100W |
|
Compressed cua: |
0.5Mpa-0.8 Mpa |
|
Qhov Loj: |
L590xW415xH900mm |
|
Khoom hnyav: |
190 KG |
Cov Khoom Paub meej
Cim npe nrov: Tuam Tshoj electrode tuag cutter manufacturers, lwm tus neeg
