Hnab looj tes Box Rau Lithium roj teeb
Order (Moq): 1set
Ua raws li: CE Certified
Pob: Plywood Case
Khoom Keeb Kwm: Tuam Tshoj
Warranty: Ib xyoos lav nrog kev txhawb nqa lub neej
Kev Them Nyiaj: T / T, Western Union, Paypal, Ali Trade Assurance
Stainless Hlau Nqus Hnab Hnab Hnab Rau Lithium Roj Teeb
Product Description
Stainless hlau nqus tsev vacuum lub thawv rau lthium roj teeb yog cov khoom siv hauv chav kuaj tuaj yeem ua rau 29.9 "ntawm Hg (0.1 Bar) uas tuaj yeem ntim nrog cov roj purity siab inert rau hauv lub thawv kom lim tawm cov khoom nquag.
Stainless hlau nqus tsev vacuum lub thawv rau lthium roj teeb muab qhov huv si, tswj qhov chaw ib puag ncig rau ntau daim ntawv thov xws li semiconductor, kev tsim tshuaj, kev tshawb fawb thiab kev sim. Stainless hlau muaj kev tiv thaiv zoo rau ntau yam tshuaj lom neeg thiab zoo heev ya raws thiab kub tsis kam. Lawv tuaj yeem decontaminated thiab ntxuav tau yooj yim, thiab lawv yog ESD muaj kev nyab xeeb tsim nyog rau kev siv hluav taws xob zoo li qub yog tias muaj av. Lawv muaj kev tswj hwm ib puag ncig rau kev ua haujlwm. Thaum siv ua ke nrog lub tshuab tswj kev tshem tawm nitrogen los yog cov pa roj purging, cais cov hnab looj tes muab qhov chaw qis thiab tsis muaj oxygen rau kev tuav cov qauv, qhov chaw, thiab cov khoom siv hluav taws xob.
Peb paub zoo tias yog ib qho ntawm cov hnab looj tes ua lag luam thiab cov muag khoom hauv Suav teb. Thov koj xav tias dawb mus yuav cov hnab looj tes zoo ntawm tus nqi sib tw los ntawm peb lub hoobkas. Rau kev pabcuam customized, tiv tauj peb tam sim no.
Nta
|
Box lub cev |
SUS304 stainless hlau, thickness 3 hli, puab nto: txhuam stainless hlau, Sab nrauv nto: tshuaj tsuag xim, dawb |
| Qhov rai | Pem hauv ntej ntawm lub thawv ua haujlwm yog ua los ntawm 10 mm tuab organic iav, nrog rau qhov pom dav thiab tsis muaj qhov muag tsis pom. |
|
Pob valve |
Lub inlet thiab qhov hluav taws xob balloon yog ua los ntawm 304 stainless hlau. Muaj cov dej nozzles sab hauv thiab sab nraum lub valve kom tso dej thiab cua nkag mus. Qee cov twj paj nruag (xws li spin coaters) tuaj yeem muab tso rau hauv lub thawv thiab tuaj yeem khiav tawm ntawm nws. |
| Teeb pom kev zoo | UV-dawb dawb lub teeb, ntsia saum toj thiab pem hauv ntej ntawm txhua lub qhov rais iav |
| Fais fab mov |
Lub thawv yog nruab nrog ntau lub qhov hluav taws xob qhov (socket) kom tau raws li qhov xav tau ntawm cov neeg siv khoom siv cuab yeej siv. |
|
Hnab looj tes |
Lub hnab looj tes ua haujlwm siv cov hnab looj tes tiv thaiv kev ua haujlwm-qib corrosion-resistant latex, thiab lub hnab looj tes lub qhov ncauj yog tsau nrog lub nplhaib sealing. |
| Reserved interface | Reserved interface rau KF, lub hnab looj tes tuaj yeem hloov kho txhua lub sijhawm tom qab. |
Specification
|
Lab hnab looj tes Box Specification |
||
|
Qauv nab npawb |
|
VGB-4 |
|
Khoom siv |
|
Stainless hlau SUS304, 3MM |
|
Main Chamber Dimension |
|
1120mm (L) × 740mm (W) × 900mm (H) |
|
Main Chamber Siab |
|
Max. Lub tshuab nqus tsev: -0.1MPa |
|
Antechamber Dimension |
|
ua los ntawm 304 stainless hlau ø360mm, ntev =435mm, sab xis, nrog slidable tais sab hauv |
|
Antechamber Siab |
|
Max. Lub tshuab nqus tsev: -0.1MPa |
|
Qhov rai vaj huam sib luag |
|
1 Transparent Pem Hauv Ntej Vaj Huam Sib Luag Tshem tau tempered qhov rais nrog 2 hnab looj tes ports (10mm) |
|
Hnab looj tes |
|
1 khub hnab looj tes Butyl |
|
Teeb pom kev zoo |
|
1 Lub teeb pom kev zoo (110V, 60Hz) |
|
Kev ntsuas siab |
|
1 Lub Siab Ntsuas ntawm Antechamber, Lub Tebchaws Yelemees WIKA hom |
|
KF Connectors |
|
Standard KF-25, KF-40 connectors thiab koob li qub |
|
Kev xaiv |
|
1 Oxygen saib xyuas chav tsev (0 -1000 PPM) Chav ntsuas dej noo (0-1000 PPM) Automatic Pressure Controller Tsis Siv Neeg Humidity Controller (1-99%RH) Solvent tshem tawm system Qhib lub voj / kaw-lub voj HEPA lim Lub tshuab nqus tsev siab ceev (4L / S Lub tshuab nqus tsev siab ceev) Purification System |
