Intermittent Experimental Txheej Tshuab

Yam khoom: ACEY-AC300J
Order (Moq): 1set
Ua raws li: CE Certified
Pob: Plywood Case
Khoom Keeb Kwm: Tuam Tshoj
Warranty: Ib xyoos lav nrog kev txhawb nqa lub neej
Kev Them Nyiaj: T / T, Western Union, Paypal, Ali Trade Assurance

Xa kev nug

Khoom Taw qhia

Intermittent Experimental Txheej Tshuab rau Lab

Product Description

Cov txheej txheem sib deev Tshwj xeeb tshaj yog siv nyob rau hauv kev lag luam roj teeb lithium-ion, cov khoom siv yog tsim los kom yooj yim rau cov neeg tshawb nrhiav siv, thiab ua kom tau raws li qhov yuav tsum tau ua ntawm txheej txheej raug thiab sib xws, uas tsis txawv ntawm ntau lawm. Cov nyhuv ziab yog zoo heev. Nws yog lithium-ion roj teeb, super capacitor, nickel roj teeb thiab lwm yam. Zoo tagnrho rau kev txhim kho roj teeb theem nrab thiab kev sim me me.

Nta

Nws tuaj yeem hloov pauv tau yooj yim kom paub cov txheej txheem txuas ntxiv thiab sib cuam tshuam;
Substrate nro tswj, ruaj khov daim kab xev mus ncig, nruab nrog deviation kho ntaus ntawv;
Cua kub qhov cub, sab sauv thiab qis dua ob sab tshuab, ua kom qhuav zoo;
Peb-yob hloov txheej txheej, nrog lub qhov rais dav txheej txheej;
Comma squeegee ntsuas, nrog precision hloov mechanism, kom tau cov txheej txheem siab;
PLC tswj, kov npo ua haujlwm, yooj yim thiab siv tau yooj yim;
Xaiv cov kuab tshuaj rov qab ua khoom siv

Specification

Khoom npe:	Intermittent sim txheej tshuab
Qauv No.:	ACEY-AC300J
fais fab mov	Ib-theem voltage AC220V ± 10% (110VAC tuaj yeem hloov kho), zaus 50Hz / 60Hz, lub zog 5KW
Gas qhov chaw	0 5-0.8MPa compressed cua
Siv ib puag ncig	Pom zoo ambient kub yog 25 ± 3 degree, av noo yog 30 ~ 90RH, tsis muaj kev vibration thiab electromagnetic cuam tshuam
Txheej hom	Nruam txheej, intermittent txheej
Qhia cov menyuam dav	300 hli
Txheej dav	Max. 250 hli
Mechanical ceev	Max.800mm/min
Txheej raug	Zoo tshaj ± 3μm (ntug yuam kev ± 5μm)
Txheej thickness	Nyob ntawm qhov loj ntawm qhov muab tshuaj, 30 ~ 200μm
Thickness kho	Kev hloov kho pub dawb, hu xov tooj qhia qhov tseeb 1μm
Txheej ntev	Ib thooj Max.5000mm, 10 ~ 100mm, qhov tseeb ± 0.5mm
Lub tshuab ziab khaub ncaws	Txheem cua kub kom qhuav (infrared ziab thiab UV kho tuaj yeem kho tau), ib ntu 800mm ntev
Qhuav kub	Max. 150 ± 5 degree, tuaj yeem teeb tsa
Kev tswj nruj	Max. 60 N
Reel txoj kab uas hla	250 hli
Winding raug	± 0.5 hli
Qhov loj me thiab qhov hnyav ntawm cov khoom siv txheej txheej:	Loj: L1750 * W1000 * H1200mm
Qhov hnyav: kwv yees li:	900KG nrog caster puag
